Image Processing Module (v5)
Overview
The Image Processing Module (v5) is a single-open-system-factor solution that provides graphic and processing capabilities by eliminating the need for a separate graphics card. The high performance P4080 processor utilizes eight cores and is linked to the e4690 graphics processor for exceptional performance in demanding environments.
Image Processing Module (v5) features include:
Image Processing Module (v5) features include:
- Eight core (e500mc @ 1.0 GHz) CPU
- 2 GB DDR3 Memory (@1000 MHz)
- 256MB Flash / 512KB NOVRAM
- AMD e4690 GPU w 512MB GDDR3
- Dual Link LVDS/Display Port Output
- TSI578 SRIO 8 port Switch
- 4 GigE network ports
- XMC Mezzanine Support
- Wind River VxWorks 6.9 & Green Hills Integrity tuMP support
- Civil DO-178B and MIL-STD-810E Qualified
- Re-layouts and alternate form factors available by request
Specifications
CPU
- P4080
Key Benefits
- 2 GB DDR3 Memory (@1000 MHz)
- 256MB Flash / 512KB NOVRAM
- 4 GigE network ports
- AMD e4690 GPU w 512MB GDDR3
- Civil DO-178B and MIL-STD-810E Qualified
- Dual Link LVDS/Display Port Output
- Eight core (e500mc @ 10 GHz) CPU
- Re-layouts and alternate form factors available by request
- TSI578 SRIO 8 port Switch
- Wind River VxWorks 69 and Green Hills Integrity tuMP support
- XMC Mezzanine Support
Certifications
- Civil DO-178B
- MIL-STD-810E
