IntuVue RDR-4000 3D Weather Radar System
Overview
IntuVue RDR-4000 is a member of Honeywell’s family of advanced weather radar systems. IntuVue automatically scans the sky at 17 tilt angles – the most in the industry – and delivers a 3-D view of the weather through an intuitive display that pilots love.
RDR-4000 uses 3-D volumetric scanning and pulse compression technologies to provide a complete view of the weather from 0 to 60,000 feet across a 320 nm detection range. Weather analysis features help pilots better understand weather hazards and calculate the best strategic and tactical responses. While the unique display capability combines both weather and terrain data to provide a more intuitive horizontal and virtual view of upcoming weather dynamics. Pilots can select individual slices of the airspace; including specific range, azimuth or altitude displays, to make more informed routing and maneuvering decisions.
IntuVue was designed using the latest technology, while competing radars still use base systems with limited tilt angles designed in the 1980s and 1990s. With IntuVue you get the full picture, from the ground to 60,000 feet.
IntuVue 4000 family of radar systems includes:
RDR-4000 uses 3-D volumetric scanning and pulse compression technologies to provide a complete view of the weather from 0 to 60,000 feet across a 320 nm detection range. Weather analysis features help pilots better understand weather hazards and calculate the best strategic and tactical responses. While the unique display capability combines both weather and terrain data to provide a more intuitive horizontal and virtual view of upcoming weather dynamics. Pilots can select individual slices of the airspace; including specific range, azimuth or altitude displays, to make more informed routing and maneuvering decisions.
IntuVue was designed using the latest technology, while competing radars still use base systems with limited tilt angles designed in the 1980s and 1990s. With IntuVue you get the full picture, from the ground to 60,000 feet.
IntuVue 4000 family of radar systems includes:
- RDR-4000
- RDR-4000M
- Radar-4000 3D
Compatible Platform
Airbus A320
Airbus A330
Boeing B737Max
Boeing B737NG
Boeing B777
Dassault Falcon F5X
Dassault Falcon F7X
Dassault Falcon F8X
Embraer E-170/175/190/195/E2
Gulfstream G650
Specifications
Weight
- 3 MCU - 10.5 lbs
Antenna Size
- 30 Inch, 24 Inch 18 Inch
- 30 in, 24 in 18 in
Maximum Detection Ranges
- 0-60,000 ft
- 320 nm
Key Benefits
- Early adopters have reported a 50-percent reduction in lightning strikes and their maintenance
- IntuVue’s system is intuitive for younger pilots, increasing retention and making it easier and cheaper to train users
- Reduce pilot fatigue
Component of
- Aircraft Environmental Surveillance System (AESS)
- IntuVue RDR-4000 3D Weather Radar System
Usually Bought With
- STC ST00595AT
Transmitter Method
- Pulse Compression
Transmitter Type
- Arsenide Solid State Gallium
Components
- Antenna
- Radar Processor
- Software
- Transmitter
Software
- RTCA DO-178B Level C
Elevation Coverage
- 0-60,000 ft
Azimuth Coverage
- +/- 80 degs - Weather and Ground Map
Transmitter Power
- 9.375 GHz
Certifications
- FAA enhanced turbulence Minimum Operational Performance Standard (MOPS)
